AZURE-1940THD
AZURE-1940THD 19mm Line Scan Lens
Large image circle optics for 4K, 8K and 16K line scan cameras.
19 mmFocal Length
30mmSensor Size
115lp/mmResolving Power
TMount
F4.0Aperture
M52×0.75Filter Thread
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of AZURE-1940THD.
- DimensionsΦ54.5×48.56mm
- Weight235.2g
- Back Focal Length30.835mm
- Filter ThreadM52×0.75
- MountT
Key Specifications
| Focal Length | 19 mm |
| Sensor Size | 30mm |
| Resolving Power | 115lp/mm |
| Mount | T |
| Aperture | F4.0 |
| Filter Thread | M52×0.75 |
| Distortion | <-3% |
| Back Focal Length | 30.835mm |
| Iris | Manual Iris |
| Dimensions | Φ54.5×48.56mm |
| Weight | 235.2g |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether AZURE-1940THD fits, or recommend a better match.
