SAM-LS85F45-C62 — 85mm Line Scan Lens (62 mm image circle)

Name: 85mm Line Scan Lens (62 mm image circle)
Brand: Samanstar
SKU: SAM-LS85F45-C62

Large image circle optics for 4K, 8K and 16K line scan cameras.

85 mmFocal Length

100 lp/mmResolving Power

62 mmImage Circle

F4.5Aperture

M52 x 0.75Filter Thread

24 hours sample dispatch · MOQ 1 pc · 1 year warranty · Express / air / sea, DDP available

Dimensions

Overall length, barrel diameter, flange distance and thread sizes, taken from the mechanical drawing. Click the drawing to enlarge it.

SAM-LS85F45-C62 (85mm Line Scan Lens (62 mm image circle)) is listed in the Line Scan range. Catalogue values include 62 mm image circle.

Before ordering, confirm the sensor coverage, mount and available working range against the current drawing and test data for this model.

Documentation is sent by email or WhatsApp while the download centre is being prepared.

60 mm · 3.5 µm(16K)/5 µm(12K) · 57.3 mm(16K)/62 mm(12K) · 16K / 12K

116 mm · 0.18-0.24 · V-Mount（φ56） · 4.5-22

116 mm · 0.7-0.85 · V-Mount（φ56） · 4.5-22

116 mm · 1.19-1.29 · V-Mount（φ56） · 4.5-22

114 mm · 0.23-0.28 · V-Mount（φ49） · 3.8-16

110 mm · 3.5μm · 43 mm · F-Mount

Tell us your sensor, working distance and application. We will confirm whether SAM-LS85F45-C62 fits, or recommend a better match.
