AZURE-NV7538M6M
AZURE-NV7538M6M 75mm Machine Vision Lens
Fixed focal lenses for automation, positioning, code reading and general inspection.
75 mmFocal Length
2/3”Sensor Size
6 MPResolution
6MPResolving Power
CMount
3.8Aperture
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of AZURE-NV7538M6M.
- DimensionsΦ36×70.5mm
- Weight-
- Back Focal Length25.683mm
- Filter ThreadM30.5×0.5
- MountC
Key Specifications
| Focal Length | 75 mm |
| Sensor Size | 2/3” |
| Resolution | 6 MP |
| Resolving Power | 6MP |
| Mount | C |
| Aperture | 3.8 |
| Working Distance | - |
| Filter Thread | M30.5×0.5 |
| Field of View | 1/2"靶面 3.93°×2.95°; 1/3"靶面 2.95°×2.21° |
| Distortion | <0.3% |
| Back Focal Length | 25.683mm |
| Iris | Manual |
| Dimensions | Φ36×70.5mm |
| Weight | - |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
