AZURE-2408M42
AZURE-2408M42 24mm Machine Vision Lens
UV, SWIR, S-mount, ITS and fully custom optical designs.
24 mmFocal Length
4/3”Sensor Size
50 Ip/mmResolving Power
M42×1Mount
F0.8Aperture
M67×0.75Filter Thread
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of AZURE-2408M42.
- DimensionsΦ76×125.5mm
- Weight-
- Back Focal Length13.14mm
- Filter ThreadM67×0.75
- MountM42×1
Key Specifications
| Focal Length | 24 mm |
| Sensor Size | 4/3” |
| Resolving Power | 50 Ip/mm |
| Mount | M42×1 |
| Aperture | F0.8 |
| Filter Thread | M67×0.75 |
| Field of View | 1"靶面 35.93°×21.91°×29.1°; 2/3"靶面 24.8°×14.88°×19.84° |
| Distortion | 5.6% |
| Back Focal Length | 13.14mm |
| Iris | Manual Iris |
| Dimensions | Φ76×125.5mm |
| Weight | - |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether AZURE-2408M42 fits, or recommend a better match.
