AZURE-1060ZM
AZURE-1060ZM 10mm Zoom Lens
UV, SWIR, S-mount, ITS and fully custom optical designs.
10 mmFocal Length
2/3”Sensor Size
100lp/mmResolving Power
CMount
F1.4Aperture
0.5m~∞Working Distance
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of AZURE-1060ZM.
- DimensionsΦ59.5×126.97mm
- Weight532.5g
- Back Focal Length10.51mm
- Filter ThreadM49×0.75
- MountC
Key Specifications
| Focal Length | 10 mm |
| Sensor Size | 2/3” |
| Resolving Power | 100lp/mm |
| Mount | C |
| Aperture | F1.4 |
| Working Distance | 0.5m~∞ |
| Filter Thread | M49×0.75 |
| Distortion | <1%~12% |
| Back Focal Length | 10.51mm |
| Iris | M-Iris |
| Dimensions | Φ59.5×126.97mm |
| Weight | 532.5g |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether AZURE-1060ZM fits, or recommend a better match.
