AZURE-0812Z5M
AZURE-0812Z5M 8mm Zoom Lens
UV, SWIR, S-mount, ITS and fully custom optical designs.
8 mmFocal Length
1/2.5”Sensor Size
200lp/mmResolving Power
CMount
F2.5~F22Aperture
0.3m~∞Working Distance
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of AZURE-0812Z5M.
- DimensionsΦ34.5×48.77mm
- Weight84.94g
- Back Focal Length10.05~12.36mm
- Filter ThreadM27×0.5
- MountC
Key Specifications
| Focal Length | 8 mm |
| Sensor Size | 1/2.5” |
| Resolving Power | 200lp/mm |
| Mount | C |
| Aperture | F2.5~F22 |
| Working Distance | 0.3m~∞ |
| Filter Thread | M27×0.5 |
| Distortion | -4%~2.0% |
| Back Focal Length | 10.05~12.36mm |
| Iris | M-Iris |
| Dimensions | Φ34.5×48.77mm |
| Weight | 84.94g |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether AZURE-0812Z5M fits, or recommend a better match.
