SAM-MCZ03-11WD0-C23
SAM-MCZ03-11WD0-C23 — 0.3X - 1.1X Macro Lens (WD 0.083m~0.103m, 2/3", C-Mount)
High magnification and variable focal length optics for small features and flexible fields of view.
0.3X - 1.1XMagnification
2/3"Sensor Size
3 MPResolving Power
C-MountMount
F7.6 - F32Aperture
0.083m~0.103mWorking Distance
Dimensions
Mechanical dimensions
Overall length, barrel diameter, flange distance and thread sizes, taken from the mechanical drawing. Click the drawing to enlarge it.
- Weight38 g
- Back Focal Length12.78 mm
- Filter ThreadM34 x 0.5
- MountC-Mount
Product overview
SAM-MCZ03-11WD0-C23 (0.3X - 1.1X Macro Lens (WD 0.083m~0.103m)) is listed in the Macro and Zoom range. Catalogue values include 2/3" sensor, C-Mount, distortion -0.1%~+1.1%, WD 0.083m~0.103m, 0.3X - 1.1X magnification.
Before ordering, confirm the sensor coverage, mount and available working range against the current drawing and test data for this model.
Key Specifications
| Magnification | 0.3X - 1.1X |
| Sensor Size | 2/3" |
| Resolving Power | 3 MP |
| Mount | C-Mount |
| Aperture | F7.6 - F32 |
| Working Distance | 0.083m~0.103m |
| Filter Thread | M34 x 0.5 |
| Distortion | -0.1%~+1.1% |
| Back Focal Length | 12.78 mm |
| Weight | 38 g |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether SAM-MCZ03-11WD0-C23 fits, or recommend a better match.
