C-FA1613A
C-FA1613A 16mm Machine Vision Lens
Fixed focal lenses for automation, positioning, code reading and general inspection.
16 mmFocal Length
1/1.7”Sensor Size
12 MPResolution
12MPResolving Power
C-MountMount
2.4-16Aperture
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of C-FA1613A.
- Dimensionsφ31×37.36(min)
- Weight60
- Filter ThreadM27×P0.5
- MountC-Mount
Key Specifications
| Focal Length | 16 mm |
| Sensor Size | 1/1.7” |
| Resolution | 12 MP |
| Resolving Power | 12MP |
| Mount | C-Mount |
| Aperture | 2.4-16 |
| Filter Thread | M27×P0.5 |
| Field of View | 1/3"视场角Angle 16.66°×12.53°; 1/1.7"视场角Angle 25.43°×19.39°; 1/2"视场角Angle 22.1°×16.66° |
| Distortion | ﹤0.1% |
| Dimensions | φ31×37.36(min) |
| Weight | 60 |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
