TD2803A 28mm Machine Vision Lens
UV, SWIR, S-mount, ITS and fully custom optical designs.
28 mmFocal Length
0.01-0.14Magnification
φ30Sensor Size
F-MountMount
2.8-16Aperture
0.4-2Working Distance
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of TD2803A.
- Dimensionsφ64×93.9
- Weight655
- Filter ThreadM62×P0.75
- MountF-Mount
Key Specifications
| Focal Length | 28 mm |
| Magnification | 0.01-0.14 |
| Sensor Size | φ30 |
| Mount | F-Mount |
| Aperture | 2.8-16 |
| Working Distance | 0.4-2 |
| Filter Thread | M62×P0.75 |
| Field of View | FOV 55° |
| Dimensions | φ64×93.9 |
| Weight | 655 |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether TD2803A fits, or recommend a better match.
