TC6552A
TC6552A Telecentric Lens
UV, SWIR, S-mount, ITS and fully custom optical designs.
0.5-2Magnification
2/3”Sensor Size
C-MountMount
65Working Distance
0.05%Distortion
φ49.2×187.3Dimensions
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of TC6552A.
- Dimensionsφ49.2×187.3
- Weight560
- MountC-Mount
Key Specifications
| Magnification | 0.5-2 |
| Sensor Size | 2/3” |
| Mount | C-Mount |
| Working Distance | 65 |
| Distortion | 0.05% |
| Dimensions | φ49.2×187.3 |
| Weight | 560 |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
Related Products
Need help choosing a lens?
Tell us your sensor, working distance and application. We will confirm whether TC6552A fits, or recommend a better match.
