LS2801A
LS2801A 29mm Line Scan Lens
Large image circle optics for 4K, 8K and 16K line scan cameras.
29 mmFocal Length
0.05-0.3Magnification
V-Mount（φ42.5）Mount
4.0-CAperture
299.7Working Distance
M35×P0.5Filter Thread
Dimensions
Mechanical drawing
(on request)
(on request)
Mechanical dimensions
Overall length, barrel diameter and flange distance. Ask us for the 2D drawing or a CAD model of LS2801A.
- Weight161
- Filter ThreadM35×P0.5
- MountV-Mount（φ42.5）
Key Specifications
| Focal Length | 29 mm |
| Magnification | 0.05-0.3 |
| Mount | V-Mount（φ42.5） |
| Aperture | 4.0-C |
| Working Distance | 299.7 |
| Filter Thread | M35×P0.5 |
| Distortion | 0.1% |
| Weight | 161 |
Applications
- Machine Vision
- Machine Vision Inspection
- Precision Measurement
- Electronics & Semiconductor
Downloads
- Datasheet (PDF)
- CAD model
- MTF data
- User manual
Documentation is sent by email or WhatsApp while the download centre is being prepared.
